รายละเอียดสินค้า:
|
แรงดันไฟฟ้า: | 110V / 220V / 380V / 415V / 480V | เฮิรตซ์: | 50HZ, 60HZ |
---|---|---|---|
วัสดุ: | CS / SUS304 / SUS316L / ไทเทเนียม | พลังงานการติดตั้ง: | 5.5KW-75KW |
อุณหภูมิอบแห้ง: | 80-250 ℃ | น้ำหนัก: | 0.5Ton-40Ton |
ทรัพยากรความร้อน: | ไอน้ำ / น้ำมันร้อน / น้ำร้อน | ประสิทธิภาพการอบแห้ง: | 85% |
วิธีการควบคุม: | ปุ่ม / หน้าจอสัมผัส / รีโมท | ออกแบบพิเศษ: | ความต้านทานการระเบิด / การอบแห้งที่อุณหภูมิต่ำ |
กำลังโหลด Capcity: | 15KGS / H-1000 กก / H | ||
แสงสูง: | เครื่องเป่าลูกกลิ้ง,เครื่องอบแห้งทรงกระบอก |
GT roller drum dryer is a kind of indirect heating dryer in continuous production. GT roller drum dryer เป็นเครื่องเป่าความร้อนทางอ้อมชนิดหนึ่งในการผลิตอย่างต่อเนื่อง Raw material fed from top or bottom of drum and stick on the drum. วัตถุดิบที่ป้อนจากด้านบนหรือด้านล่างของถังและติดบนถัง Filling steam or thermal oil inside the drum, the heat then transferred to raw material, thus raw material could get dried. เติมไอน้ำหรือน้ำมันความร้อนภายในถังความร้อนจากนั้นย้ายไปยังวัตถุดิบทำให้วัตถุดิบแห้ง Flake form dried product will be scraped off, and preliminarily crushed as well as transported by screw conveyor. ผลิตภัณฑ์อบแห้งแบบเกล็ดจะถูกคัดออกและบดเบื้องต้นและขนส่งโดยสกรูลำเลียง
ความชื้นระเหยจะถูกดูดออกโดยพัดลมดูดอากาศ
เครื่องเป่านี้เหมาะสำหรับของเหลวหรือวัตถุดิบที่มีความหนืด
(1)High efficiency. (1) ประสิทธิภาพสูง Almost all of the heat could be used on drying, drying efficiency could reach 80-90%. ความร้อนเกือบทั้งหมดสามารถนำมาใช้ในการอบแห้งประสิทธิภาพการอบแห้งสามารถถึง 80-90%
(2)Widely used. (2) ใช้กันอย่างแพร่หลาย The dryer is available for drying the raw material with large moisture content range. เครื่องเป่ามีไว้สำหรับการอบแห้งวัตถุดิบที่มีช่วงความชื้นสูง We could get the best drying effect by adjust feeding rate, thickness of pavement, drum rotating speed, feeding form etc. เราสามารถรับผลการอบแห้งที่ดีที่สุดโดยปรับอัตราการให้อาหารความหนาของผิวทางความเร็วในการหมุนของกลองรูปแบบการให้อาหาร ฯลฯ
(3) Short retention time. (3) เวลาเก็บสั้น Drying time only remains 10-15 seconds, it is suitable for heat sensitive material. เวลาในการอบแห้งเหลือเพียง 10-15 วินาทีเท่านั้นจึงเหมาะสำหรับวัสดุที่ไวต่อความร้อน
